Navisworks for Construction Review and Coordination

Navisworks is a 3D design review package for Windows. It is compatible with most major native design and laser-scan file formats, and can create construction sequences in 4D. This helps in coordination and clash detection, reducing costs and improving control of the overall project.

Create 4D construction sequences

Navisworks is a time liner tool that helps plan construction projects by analyzing and visualizing design and construction activities. It can import data from other software. Then it combines planning files with a 3D model to simulate the entire construction process. This helps improve project efficiency and reduces construction risk.

A lot of planning, coordinating and communicating happens during the construction process. These activities can be monitored and tracked in a virtual simulation. This provides valuable insights about the logistics and costs of a project.

Before starting a construction project, the construction team should work together to identify and address potential problems. Pre-construction coordination reduces clashes and improves the construction’s ability to deliver on time and within budget.

Planning a large-scale construction project is always challenging. For example, densely populated areas are difficult to navigate, and materials delivery routes must be carefully planned.

Improve coordination by running clash detection

Navisworks is a powerful software tool for coordination. It provides advanced visualization and simulation to help design teams achieve quality outcomes. With an increase in the use of BIM by architects, engineers, and structural engineers, Navisworks has become an indispensable tool.

Navisworks has built-in clash detection, enabling users to check for potential overlaps in designs. This can reduce construction costs and delays. In fact, the Association of Construction and Development estimates that each identified clash will save the industry an average of $17,000.

Navisworks also has a graphical interface that makes it easy to identify and analyze issues. This includes a Clash Detective tool, which conducts clash tests between laser-scanned point clouds. The tool can be used independently or in combination with other Navisworks tools.

In addition to the Clash Detective, Navisworks supports time-based clash detection. Using this feature, project leaders can create and execute specific cross-discipline class tests. These tests will allow them to track the most critical constructability issues.

Reduce costs in the long run

The name of the game in construction is productivity, and a recent McKinsey survey found that 30% of construction cost is attributed to productivity issues. Using software like Navisworks is one way to keep costs down, while still maintaining the integrity of your designs. This software package is also a must have for large projects that require many 3D models to be integrated. Likewise, using this program will ensure that you are not left behind in the race to get your project done on time and within budget.

Navisworks is a robust package that pulls in different 3D computer generated models. It is also able to integrate data from other BIM platforms, such as Revit. The software has a robust set of features, allowing you to optimize your 3D designs for the best possible outcome.

Improve control over the outcomes of the entire project

Navisworks is a powerful software application for review and coordination. It is a great tool for ensuring a successful construction project. As a result, it can significantly speed up the design process. In addition, it offers more control over the entire project, which helps reduce delays and discrepancies.

When used with Autodesk BIM 360, it offers an integrated solution for design and construction projects. It provides a single data environment for all members of the project team. This integration ensures that everyone works in a consistent environment. Similarly, it allows time-saving automation of the construction process.

Autodesk Navisworks solutions are built to systematically combine design data from different file formats. The software also supports collaboration with other users.

For example, if a project team has a model created in Revit, they can easily import it into Navisworks. This way, the team can visualize the integrated model. Also, they can create 3D animations and fly-throughs.
